B600

Performance raising heavy Duty 4-wheel counterbalanced forklifts

The B600 range is suitable to be used in many intensive applications. As a result of the compact dimensions, the CESAB B600 can work in narrow indoor areas, while the availability of cabin configurations, powerful heating systems and the high index of motor protection, the B600 is suitable to be used in intensive outdoor applications, even as an alternative to IC trucks.

For customers that want to switch from internal combustion to electric trucks, the CESAB B600 series can meet the challenge. The easy and quick battery exchange options allow the CESAB B600 to be more competitive in terms of uptime, lowering the material handling operational costs and producing no emissions.

Main B600 applications are found in manufacturing plants, being used as feeder trucks to line side, long distance transport activities and heavy press/ die handling for large tonnages.

The CESAB B600 are also popular in the distribution industry for warehouse stacking/loading and unloading and for outside loading and unloading even on uneven floors.

Adaptable to improve usability, the CESAB B600 is perfect for operations in the pharmaceuticals, food and even corrosive, wet and salty environments.

Thanks to the increased residual capacity, powerful motors and large batteries B600 can be used also for applications requiring multi-forks, clamps or special attachments.

The Cesab 80V 4-wheel AC electric forklift range helps achieve the highest levels of workplace productivity.

Off

Receive my quotation

Contact us

Specifications

Model Code B620
Power Unit Electric
Load Capacity (Q) 2000 kg
Load Centre (c) 500 mm
Lift Heights (h3) 3260 mm
Travel Speed with/without load 16 / 16 km/h
High performance version 19 / 20 km/h
Lifting Speed with/without load 0,43 / 0,60 m/s
High performance version 0,46 / 0,63 m/s
Turning Radius (Wa) 2025 mm
Battery Voltage/Rated Capacity (5h) 80V / 500-620Ah
Model Code B625 B625L B625HL
Power Unit Electric  Electric  Electric
Load Capacity (Q) 2500 kg  2500 kg  2500 kg
Load Centre (c) 500 mm  500 mm  600 mm
Lift Heights (h3) 3260 mm  3260 mm  3260 mm
Travel Speed with/without load 16 / 16 km/h  16 / 16 km/h  16 / 16 km/h
High performance version 19 / 20 km/h 19 / 20 km/h 19 / 20 km/h
Lifting Speed with/without load 0,38 / 0,60 m/s  0,38 / 0,60 m/s  -- / -- m/s
High performance version 0,46 / 0,63 m/s 0,46 / 0,63 m/s 0,40 / 0,55 m/sh
Turning Radius (Wa) 2025 mm 2175 mm 2175 mm
Battery Voltage/Rated Capacity (5h) 80V / 560-620Ah 80V / 700-775Ah 80V / 700-775Ah
Model Code B630 B630L B630HL
Power Unit Electric Electric Electric
Load Capacity (Q) 3000 kg  3000 kg 3000 kg
Load Centre (c) 500 mm  500 mm 500 mm
Lift Heights (h3) 3260 mm  3260 mm 3260 mm
Travel Speed with/without load 16 / 16 km/h 16 / 16 km/h 16 / 16 km/h
High performance version 19 / 20 km/h 19 / 20 km/h 19 / 20 km/h
Lifting Speed with/without load 0,34 / 0,52 m/s 0,34 / 0,52 m/s -- / -- m/s
High performance version 0,40 / 0,55 m/s 0,40 / 0,55 m/s 0,40 / 0,55 m/s
Turning Radius (Wa) 2038 mm 2175 mm 2200 mm
Battery Voltage/Rated Capacity (5h) 80V / 560-620Ah 80V / 700-775Ah 80V / 700-775Ah
Model Code B635
Power Unit Electric
Load Capacity (Q) 3500 kg
Load Centre (c) 600 mm
Lift Heights (h3) from 3260 mm
Travel Speed with/without load 16 / 16 km/h
High performance version 19 / 20 km/h
Lifting Speed with/without load -- / -- m/s
High performance version 0,37 / 0,55 m/s
Turning Radius (Wa) 2200 mm
Battery Voltage/Rated Capacity (5h) 80V / 700-775Ah
Model Code B640
Power Unit Electric
Load Capacity (Q) 4000 kg
Load Centre (c) 500 mm
Lift Heights (h3) from 3300 mm
Travel Speed with/without load 17.5/17.5 km/h
Lifting Speed with/without load 0.33/0.47 m/s
Turning Radius (Wa) 2589 mm
Battery Voltage/Rated Capacity (5h) 80V / 750-930 Ah
Model Code B645
Power Unit Electric
Load Capacity (Q) 4500 kg
Load Centre (c) 500 mm
Lift Heights (h3) from 3300 mm
Travel Speed with/without load 17.5/17.5 km/h
Lifting Speed with/without load 0.33/0.47 m/s
Turning Radius (Wa) 2609 mm
Battery Voltage/Rated Capacity (5h) 80V / 750-930 Ah
Model Code B650
Power Unit Electric
Load Capacity (Q) 5000 kg
Load Centre (c) 600 mm
Lift Heights (h3) from 3300 mm
Travel Speed with/without load 17.5/17.5 km/h
Lifting Speed with/without load 0.31/0.44 m/s
Turning Radius (Wa) 2701 mm
Battery Voltage/Rated Capacity (5h) 80V / 750-930 Ah
